Rode NT5

Rp4.100.000Rp8.000.000

Package Clear

Description



Rode NT5

The NT5 is RØDE’s premier small-diaphragm cardioid condenser microphone, sometimes referred to as a ‘pencil mic’.

Intended for recording acoustic instruments, drum overheads, cymbals and live performances, the compact externally polarized mic employs a 1/2″ capsule, an active J-FET impedance converter with bipolar output buffer.

Its tight cardioid pickup pattern also makes it ideal for use as an indoor dialogue microphone for filmmaking on a mic stand or boom.

Expanding the NT5’s versatility, an interchangeable omnidirectional capsule (NT45-O) is available.

Finished in durable satin nickel, the NT5 available as a single microphone or as an acoustically matched pair.

Features:

  • Externally biased condenser
  • Gold sputtered 1/2” capsule
  • Heavy-duty satin-nickel plated body
  • Dual power operation
  • Surface mount circuitry
  • Low noise
  • Full frequency response
  • Available as Certified Match Pair

Specifications:

Acoustic PrinciplePressure Gradient
Active ElectronicsJFET impedance converter with bipolar output buffer
Capsule0.50″
Polar PatternCardioid
Address TypeEnd
Frequency Range20Hz – 20kHz
Output Impedance100Ω
Maximum SPL143dB SPL (@ 1kHz, 1% THD into 1KΩ load)
Maximum Output Level13.9mV
Sensitivity-38.0dB re 1 Volt/Pascal (12.00mV @ 94 dB SPL) +/- 2 dB @ 1kHz
Equivalent Noise Level (A-weighted)16dB-A
Power OptionsP24, P48
Weight101.00gm
Dimensions118.00mmH x 20.00mmW x 20.00mmD
OutputXLR
