Rane Four

Rp25.000.000

Description

RANE has produced the ultimate DJ setup, in collaboration with Serato, providing superior Stems control.

Fusing the renowned industrial-grade build and sound quality of RANE hardware with the powerful new Stems capabilities of Serato DJ software, ensures the RANE FOUR will always be by your side, no matter the battle.

Harness The Power of STEMS

The most advanced Serato Stems DJ controller with dedicated Stems pad mode, independent Acapella/Instrumental buttons, and exclusive STEM-SPLIT feature for the ultimate Stems workflow and experience

Dedicated Pad Displays

Focus On Your Performance, Not Your Laptop

The 8 OLED displays above the 16 Performance Pads offer visual feedback for all pad modes. See Cue, Loop, Sample names, Roll and Loop lengths, beat divisions, Pitch Play tuning, Stem elements and FX

Creative Performance Features

Add flavor to your individual Stems and tracks with the 22 hardware Main FX and 4 knob-controlled Channel FX like Reverb, Scale Down Echo, Recycler, Riser, Filter, Filter Roll, Noise, Flanger and more

4-Channel Mixer

Four Channels of Performance Possibility

4-Channel mixer with full EQ control, intuitive FX assignment, enhanced Sampler routing and quick-access jog wheel deck selection buttons and 2 external Line/Phono ins for external turntables or decks

Creative FX and MAG FOUR Crossfader

Access Serato DJ Pro with Pitch ‘n Time. Complement your performance using the MAG FOUR tension-adjustable crossfader with contour control to adjust the slope of the crossfader curve

8.5″ Jog Wheels

Be In Full Control of Your Mix!

Mix with 8.5″ responsive jog wheels and 8 pads with Stems, Hot Cue, Saved Loop, Roll, Sampler, Slicer and Combo Pad mode enabling 2 modes at once – one for the top pads and one for the bottom ones

Serato DJ Pro Included

From the main stage to the underground, Serato DJ Pro is the trusted DJ software app for the DJing elite. Renowned for its reliability and packed with features to empower outstanding performances

Serato Pitch ‘n Time DJ Included

A renowned Time-Stretching and Key-Shifting algorithm that gives you the creative freedom to shift and sync the key of your tracks, or to speed up and slow them down to extreme tempos

Tech Specs

Digital Audio
  • Converters: Cirrus Logic, 24-bit PCM, 48 kHz
  • Digital Signal Processing: 32-bit, Floating Point, Double precisio
  • Dynamic Range (A-weighted, unity gain):
    • ADC: 113 dB
    • DAC: 113 dB
    • CD Input to Analog Output: 110 dB
    • CD Input to USB Output: 113 dB
    • USB Input to Analog Output: 113 dB
Inputs
  • Microphone 1/2 (Combo XLR/1/4″ [6.35 mm] TRS):
    • Analog Gain: 25 dB
    • Maximum Input: 110 mV
    • Gain Trim: Off to +26 dB (unity at center)
    • Tone Control: 2-band
  • Line/Phono Inputs 3/4 (RCA stereo pairs, switchable):
    • Line: Line
    • Maximum Input: 4 Vrms
    • Gain Trim: Off to +12 dB
    • Tone Control: 3-band, full-cut to +10 dB
    • THD+N (20 kHz BW @ 1 kHz: 0.004%
    • Phono: RIAA
    • RIAA Curve: +/-0.25 dB
    • Gain (@ 1 kHz): 31.5 dB
    • Maximum Input (@ 1 kHz): 106 mV
    • Dynamic Range (A-weighted): 102 dB
Outputs
  • Main Outputs (XLR):
    • Gain Trim: Off to 0 dB
    • Maximum Output: 8 Vrms
    • THD+N (20 kHz BW @ 1 kHz): 0.004%
    • Frequency Response: Flat – 20-20kHz
  • Main Outputs (RCA stereo pair):
    • Maximum Output: 4 Vrms
    • THD+N (20 kHz BW @ 1 kHz): 0.004%
    • Frequency Response: Flat – 20-20kHz
  • Booth Outputs (1/4”):
    • Gain Trim: Off to 0 dB
    • Maximum Output: 8 Vrms
    • THD+N (20 kHz BW @ 1 kHz): 0.004%
    • Frequency Response: Flat – 20-20kHz
  • Headphone Outputs (1/4″/6.35 mm and 1/8″/3.5 mm TRS):
    • Maximum Output: 4 Vrms Voltage: (no load)
    • Output Power: 50 mW (50 ohms)
    • Dynamic Range (A-weighted): 108 dB
Pads
  • (16) on/off multi-color back-lit pads (8 per deck, 9 modes each
Wheel Displays
  • (2) 320 x 240 Color LCD’s
Pad & FX Displays
  • (9) 128 x 32 Monochrome OLED’s
Faders
  • (1) MAG FOUR tension-adjustable crossfader with contour
  • (4) Standard channel faders
Connections
  • (2) XLR outputs (Main)
  • (2) 1/4” outputs (Booth)
  • (1) RCA stereo output pair (Main)
  • (2) XLR / 1/4” (6.35 mm) TRS inputs (Mic 1–2)
  • (2) RCA stereo input pairs (Deck 3-4)
  • (1) 1/4” (6.35 mm) TRS output (Headphones)
  • (1) 1/8” (3.5 mm) TRS output (Headphones)
  • (2) USB Type-B ports
  • (1) IEC power cable input
Power
  • Connection: IEC
  • Voltage: 100–240 V, 50/60 Hz
  • Consumption: 20 W
Dimensions
  • Dimensions (width x depth x height): 30.8” x 15.9” x 4.2”
    782.32 x 403.8 x 106.6 mm
Weight (including platters)
  • 18.25 lbs.
    8.27 kg
